N116BGE-EA2
11.6-inch Slim 30-pin HD LCD Panel
N116BGE-EA2 is an 11.6-inch widescreen HD LCD panel with 1366 × 768 resolution, a matte anti-glare surface, a 30-pin eDP interface, and side mounting brackets. The video connector is 0.75 inch (19 mm) wide.
- Screen size
- 11.6 inch
- Resolution
- 1366 × 768
- Panel type
- TN
- Connector
- EDP
- Pin count
- 30
- Touch
- No
- Availability
- Available on request
- Minimum order
- 10
Technical specifications
- Screen size
- 11.6 inch
- Resolution
- 1366 × 768
- Panel type
- TN
- Connector
- EDP
- Pin count
- 30
- Touch
- No
- Brightness
- 220 nits
- Refresh rate
- 60 Hz
- Surface
- Matte / Anti-Glare (3H)
- Backlight
- LED
Product specification manual
PDF document
N116BGE-EA2 Product Specification
3.20 MB
