Notebook LCD Panels · AXVISION
N156KME-GNA
15.6-inch Slim 40-pin QHD 165 Hz IPS LCD Panel
N156KME-GNA is a 15.6-inch slim QHD IPS LCD panel with 2560 × 1440 resolution, a matte anti-glare surface, a 40-pin eDP 1.3 interface, and no mounting brackets. It delivers 300 nits brightness, a 165 Hz refresh rate, 100% DCI-P3 color gamut, LED backlighting, 16.7 million colors, and a slim 2.6 mm maximum panel profile.
- Screen size
- 15.6 inch
- Resolution
- 2560 × 1440
- Panel type
- IPS
- Connector
- EDP
- Pin count
- 40
- Touch
- No
- Availability
- Available on request
- Minimum order
- 10
Technical specifications
- Screen size
- 15.6 inch
- Resolution
- 2560 × 1440
- Panel type
- IPS
- Connector
- EDP
- Pin count
- 40
- Touch
- No
- Brightness
- 300 nits
- Refresh rate
- 165 Hz
- Surface
- Matte / Anti-Glare (3H)
- Backlight
- LED
Product specification manual
PDF document
N156KME-GNA Product Specification
3.68 MB
